Marshall Major II Overview

Type: On-ear
Form factor: Closed-back
Connection type: Wired/Wireless
Wireless: Yes
Bluetooth version: 4.0
Driver size: 40 mm
Frequency response: 10 Hz – 20 kHz
Impedance: 32 Ω
Sensitivity: 99 dB
Microphone: Yes
Battery life: Up to 30 hours
Charging time: 2 hours
Controls: On-ear controls for playback and calls
Weight: 200 g
Colour: Black
Brand: Marshall
Model: Major II
Year: 2016
Additional features: Foldable design, Customizable sound via app, Built-in microphone for calls

Summary of Contents

• Page 1: Page 1
• Page 2: GET UNPLUGGED. THE MAJOR II BLUETOOTH GIVES YOU THE FREEDOM AND CONVENIENCE OF A WIRELESS HEADPHONE COMBINED WITH OVER 50 YEARS OF TRIED AND TRUE MARSHALL PERFORMANCE. SEAMLESSLY CONNECT TO YOUR BLUETOOTH®-ENABLED LISTENING DEVICE AND ENJOY 30+ HOURS OF MUSIC*. TURN ON, TUNE IN AND ROCK OUT TO THE CUSTOMISED DRIVERS, WHICH DELIVER A SOUND THAT IS TIMELESS AND SURE TO BE REMEMBERED. * CALCULATED WITH RANDOMLY SELECTED MUSIC CONTENT PLAYING AT MEDIUM VOLUME.
• Page 3: DEVICE LAYOUT includes the POWER BUTTON, CONTROL KNOB, MICRO USB SOCKET FOR CHARGING, 3.5 MM INPUT/OUTPUT SOCKET, and MICROPHONE. CONTROLS for answering incoming calls, rejecting or ending calls, adjusting volume, and playing or pausing songs are managed through the CONTROL KNOB.
• Page 4: Page 4
• Page 5: POWER ON/OFF: Push and hold the power button for 4 seconds to turn on or off. BLUETOOTH® PAIRING: Double click the power button to initiate pairing; the indicator flashes blue. CHARGING: The red battery indicator blinks when low; it stays lit while charging and turns white when fully charged. PHONE FUNCTIONALITY: Wirelessly answer, reject, or end a call using the control knob. SHARING: Use the empty 3.5mm socket to share your audio.
• Page 6: TRANSDUCER: 40 MM, DYNAMIC IMPEDANCE: 64 OHM FREQUENCY RANGE: 10 HZ-20 KHZ SENSITIVITY: 100 MV @ 1 KHZ = 99 DB SPL IF YOUR BATTERY DIES, SIMPLY PLUG IN THE DOUBLE-ENDED CORD WITH BUILT IN MIC AND REMOTE. COMPATIBLE WITH ANY MUSIC PLAYER THAT RECEIVES A 3.5 MM JACK. THE BUILT-IN MICROPHONE ALLOWS YOU TO TAKE CALLS OR RECORD VOICE MEMOS THROUGH YOUR DEVICE. CLICK ONCE TO ANSWER INCOMING CALLS OR HANG UP, AS WELL AS PLAY AND PAUSE YOUR MUSIC. CLICK TWICE TO FAST FORWARD YOUR MUSIC. CLICK THREE TIMES TO REWIND.
• Page 7: PROBLEM AND ACTIONS FOR TROUBLESHOOTING HEADPHONES NOT POWERING ON: Charge the headphone using the USB cable and ensure the USB power source is switched on. NOT CHARGING: Ensure the headphone is connected properly. NOT PAIRING: Move the devices closer together and ensure the headphone is not connected to a different sound source. NO SOUND: Make sure the headphone is on and connected, and that the sound source is playing. POOR SOUND QUALITY: Move the devices closer to each other and away from any interference or obstruction.
• Page 8: This product shall not be treated as household waste and should be handed over to the applicable collection point for recycling. To prevent possible hearing damage, do not listen at high volume levels for long periods. Contains small parts which may be a choking hazard. Not suitable for children under age three. Set a low volume setting before using the headphones. Do not use these headphones when operating a motor vehicle, a bicycle, machinery, or where your inability to hear outside sounds may present a danger to you or others. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This product is in compliance with the essential requirements and other relevant provisions of Directive R&TTE 1999/5/EC and the RoHS directive 2011/65/EU.
