ATH-DSR5BT

User Manual

Wireless Headphones

https://manual-hub.com/

VIEW FULL SCREEN PDF USER MANUAL

(No Ratings Yet)

Loading...

• ALL HEADPHONE INSTRUCTIONS & USER MANUALS
• Audio-technica

Audio-technica ATH-DSR5BT Wireless Headphones Overview

Type: Over-ear
Connection type: Wireless
Bluetooth version: 4.2
Driver size: 45 mm
Frequency response: 5 – 40,000 Hz
Impedance: 38 Ω
Sensitivity: 98 dB
Microphone: Yes
Battery life: Up to 15 hours
Charging time: 4 hours
Controls: Touch controls
Weight: 310 g
Colour: Black
Brand: Audio-Technica
Model: ATH-DSR5BT
Low Latency Mode: Yes
Fast Pairing: Yes

Summary of Contents

• Page 1: Wireless Headphones User Manual
• Page 2: Thank You For Purchasing This Audio-technica Product. Before Using The Product, Please Read Through The Quick Start Guide And Caution Guide, As Well As This User Manual. To Ensure Safety, Observe All Warnings And Cautions While Using The Product. Do Not Use The Product Near Medical Equipment, As Radio Waves May Affect Cardiac Pacemakers And Medical Electronic Equipment. Do Not Charge With Devices That Have Quick-charge Functionality (with A Voltage Of 5 V Or More) To Avoid Malfunction.
• Page 3: Safety Precautions For Rechargeable Battery Usage Are Critical To Prevent Accidents And Injuries. If Battery Fluid Contacts Eyes Or Mouth, Immediate Rinsing And Medical Consultation Are Necessary. The Internal Rechargeable Battery Cannot Be Replaced By The User And Should Be Repaired By A Dealer If Performance Declines. Proper Disposal Of The Built-in Rechargeable Battery Is Essential To Avoid Environmental Hazards. This Device Complies With Fcc And Industry Canada Regulations Regarding Rf Exposure And Interference.
• Page 4: Be Sure To Read The Connected Devices User Manual Before Use. When You Are Not Using The Usb Charging Cable, Disconnect It From The Product. Audio-technica Will Not Be Liable For Any Loss Of Data While Using The Product. When Using The Product In A Dry Environment, You May Feel A Tingling Sensation In Your Ears Due To Static Electricity. To Protect The Built-in Rechargeable Battery, Charge It At Least Once Every 6 Months.
• Page 5: Part Names And Functions Include The Left/right Indicator, Control Button, Housing, Bushing, Cable Slider, Neck Band, Volume Buttons, Power Switch, Indicator Lamps, And Battery Jack. The Control Button Is Used To Play/pause Music And Answer/end Phone Calls. Volume Buttons Adjust The Volume Using + And . The Power Switch Turns The Power On And Off. Indicator Lamps Display The Operating Status And Battery Level Of The Product. Included Accessories Are A Usb Charging Cable, Eartips In Various Sizes, And A Pouch.
• Page 6: Fully Charge The Battery When Using For The First Time. When The Rechargeable Battery Is Running Low, The Product Will Beep Through The Headphones, And An Indicator Lamp Will Flash In Red. It Takes About 3 Hours To Charge The Battery Fully. While Charging The Battery, The Products Bluetooth Connection Remains Disabled. The Included Usb Charging Cable Is Designed For Exclusive Use With The Product.
• Page 7: Connecting The Product To A Bluetooth Device Requires Pairing. Once Paired, Reconnection Is Necessary If The Product Is Deleted From The Bluetooth Devices Connection History, Sent For Repair, Or If 9 Or More Devices Are Paired. The Product Can Save Pairing Information For Up To 8 Devices. To Pair A Bluetooth Device, Ensure It Is Within 1 M (3.3') Of The Product And Follow The Pairing Process As Outlined In The User Manual. If Prompted For A Passkey During Pairing, Enter '0000'.
• Page 8: The Product Can Use Bluetooth Wireless Technology To Connect To Your Device And Play Music, Receive Phone Calls, Etc. Note That Audio-technica Cannot Guarantee The Operation Of Displays Or Applications Via Bluetooth Devices. Slide The Power Switch To The 'on' Or 'off' Position. The Indicator Lamps Light From Right To Left To Indicate That The Product Is In 'pairing' Mode. Insert The Side Of The Product Marked 'l' (left) Into The Left Ear And The Side Marked 'r' (right) Into The Right Ear, And Then Adjust The Eartips.
• Page 9: Using The Product Listening To Music To Connect For The First Time, Pair The Product And Your Device Via Bluetooth Wireless Technology. Use Your Bluetooth Device To Start Playback, Referring To The Devices User Manual As Necessary. Press Play/pause To Play Or Pause Music And Video Playback. Depending On The Connected Device, Activates The Devices Speech Recognition Feature. The Volume Control Of Some Devices May Not Work Well With The Product.
• Page 10: The Product Is Compatible With Qualcomm Aptx Hd Audio, Qualcomm Aptx Audio, Aac, And Sbc Codecs. The Appropriate Codec Is Determined Automatically During The Bluetooth Pairing Process. Indicator Lamps Display The Connection Codec Used During Playback. To Switch To A Mode Incompatible With The Aptx Hd Codec, Specific Button Combinations Must Be Used While The Power Is Off. To Switch To Sbc Priority Connection Mode, Hold The Volume '' Button While Turning The Power On.
• Page 11: Using The Product If Your Bluetooth Device Supports Telephone Features, You Can Use The Product To Talk On The Phone. When Your Bluetooth Device Receives A Phone Call, The Product Sounds A Ring Tone. If A Call Is Received While You Are Listening To Music, Music Playback Is Paused. The Product Automatically Turns Off After 5 Minutes Of Not Being Connected To A Device. If The Product Does Not Work Or Other Malfunctions Occur, Refer To 'charging The Battery' And Connect The Usb Charging Cable That Is Carrying Power, And Then Reset The Product.
• Page 12: Get Into The Habit Of Regularly Cleaning The Product To Ensure That It Will Last For A Long Time. Do Not Use Alcohol, Paint Thinners, Or Other Solvents For Cleaning Purposes. Immediately Wipe Off Any Moisture Such As Sweat That Enters The Battery Jack To Prevent Malfunction Due To Corrosion. Natural Oils From The Skin Can Build Up On The Eartip Attachment Parts; Clean Them Regularly To Prevent Eartips From Becoming Detached. Wipe Away Any Perspiration Or Dirt From The Cable With A Dry Cloth Immediately After Use To Prevent Deterioration And Malfunction.
• Page 13: Eartip Size Includes Silicone Eartips In 4 Sizes (xs, S, M, And L), With M-size Attached At Purchase. Select The Eartip Size That Ensures The Best Sound Quality And A Snug Fit In Your Ears. Replacing Eartips Involves Removing The Old One And Securely Attaching The New One At An Angle. Eartips Should Be Periodically Cleaned To Prevent Dirt Accumulation That Can Deteriorate Sound Quality. If Eartips Are Loose Or Degraded, Replacements Should Be Purchased To Avoid Potential Injury Or Illness.
• Page 14: Troubleshooting Section Provides Solutions For Common Issues. Power Issues Can Often Be Resolved By Charging The Product. Pairing Problems May Require Proximity Adjustments And Profile Settings. Sound Issues Can Be Addressed By Checking Volume Levels And Connection Types. Charging Difficulties May Stem From Improper Cable Connections.
• Page 15: The Indicator Lamp Of The Product Indicates The Products Status. For Information About How The Indicator Lamps Indicate The Battery (charging) Status, See 'charging The Battery' (p. 5). For Information About How The Indicator Lamps Indicate The Codec, See 'compatible Codecs' (p. 9). Each Lamp Turns On In Order From Right To Left. All Lamps Turn Off For 3 Seconds.
• Page 16: Specifications For Headphones Include Dynamic Type, Driver Size Of 9.8 Mm And 8.8 Mm, And Sensitivity Of 102 Db/mw. The Frequency Response Ranges From 5 To 45,000 Hz With An Impedance Of 10 Ohms. The Microphone Is An Electret Condenser Type With Omnidirectional Polar Pattern And Sensitivity Of -42 Db. Communication Specifications Detail Bluetooth Version 4.2 With A Maximum Communication Range Of Approximately 10 M. Power Supply Is A Dc 3.7 V Lithium Polymer Battery With An Operating Time Of Max. Approx. 8 Hours And A Charging Time Of Approx. 3 Hours.
• Page 17: 2018 Audio-technica Corporation Global Support Contact: Www.at-globalsupport.com 02-01 Ver.1 04.15
